Enhance your outdoor power backup infrastructure with our UPS1048 v2-802-10 Package Deal, delivering superior performance and reliability for your outdoor applications. LinkPower™ UPS1048V2 Outdoor IP68 Uninterruptible Power Supply 1048V2 provides AC to a 7Ah AGM battery backup, 48V DC and 260W output, with a fast battery charge of 1.5A.

The package includes:

1. UPS1048v2 - Outdoor Uninterruptible Power Supply:

LinkPower™ UPS1048V2 Outdoor IP68 Uninterruptible Power Supply 1048V2 provides AC to a 7Ah AGM battery backup, 48V DC and 260W output, Fast Battery Charge 1.5A, Support AGM & LFP battery packs.

Features overload and over-voltage protection and includes an AGM sealed lead-acid battery backup housed in a weather-protected IP68 enclosure.

Provides a wide input voltage range (100 to 240V AC) to deliver a nominal 48V DC and 260W output.

2. LPS3802ATMP Layer 2+ Managed Industrial PoE Switch:

Inscape Data’s LinkPower™ LPS3802ATMP is an industrial 10-port Layer 2+ managed PoE switch, offering 8x 802.3bt 1 Gigabit PoE ports and 2 SFP Uplink Ports with dual power input redundancy.

With rich L2+ management features, this switch optimizes network bandwidth and delivers information and applications more efficiently and reliably. Ideal for commercial network and enterprise applications requiring concentrated network bandwidth and high PoE power capability.

Gigabit transmission increases bandwidth for higher performance and quick transfer of large amounts of triple-play services across networks.

In The Box:

• UPS1048 v2
• LPS3802ATMP

• 7Ah AGM battery (4)
• WM0001 Wall Mounting Kit
• 16 AWG AC Power Cord
• Thermostat Fan Kit
• User Manual
• Warranty Sheet
• MMK0001-XL Pole Mount Kit (Optional)

AGM Battery Dimension:

1. Battery 7 Ah - 151x65x95 mm

2. Battery 12 Ah - 151x98x95 mm

Download Product Datasheets:

• Outdoor UPS PoE Switch Systems
• LPS3802ATM
• High-Performance Fan
• Dual Adjustable Thermostat
